Description
Product Information
Introducing the Mila gearbox, a genuine replacement designed for durability and reliability. Please note that the fixing points are not threaded, so self-tapping screws will be necessary. Use 4mm x 30mm screws (Part Number: M430CSK) to create the required threads. Remember, if you test the gearbox before installation, it will not function correctly until it is securely attached to the faceplate and connecting rods.
Mila gearboxes come in two configurations: latch only and latch with deadbolt, available in both double and single spindle options.
-
Latch Only Versions: Always single spindle, available in backsets of 25mm, 28mm, 35mm, and 45mm.
-
Latch and Deadbolt Versions:
- Single spindle (92mm PZ) available in 35mm and 45mm backsets.
- Double spindle available with a 35mm backset only, featuring a 70mm/92mm PZ measurement.
Operation: Lift lever
Latch Reversal: To reverse the latch, simply undo the screw on the side of the lock case, remove the latch, reverse it, reinsert, and replace the screw.
Product Specification
- Manufacturer: Mila
- Backset: 35mm - How do I measure the backset?
- Centres PZ: 92mm - How do I measure the centres?
- Case Height: 233mm
- Case Width: 55mm
- Copy/Genuine: Genuine
- Cylinder Type: Euro
- Handing: Not Handed
- Main Gearbox: Latch & deadbolt
- Spindle: Single 8mm
- Operation: Lift Lever - What is the operation?
- Packaging: Supplied in singles
