Product Overview: GU Secury A2 Lock
The GU Secury A2 lock is designed for enhanced security and ease of use, featuring an innovative automatic slam-shut mechanism. This lock is ideal for composite and timber doors in residential developments, ensuring that your door remains secure without requiring manual operation of the handle.
Key Features:
-
Automatic Locking: The lock engages automatically as the door closes, thanks to top and bottom actuators that trigger the deadbolts. This feature eliminates the need for manual locking, providing peace of mind.
-
Deadbolt Security: With four deadbolts in place, the lock ensures that the door is firmly secured. The center deadbolt can be activated using a key or thumb-turn, locking the other deadbolts in position.
-
High Positioning: The main gearbox is positioned higher, aligning with traditional timber door nightlatches, making it a versatile choice for various door types.
-
Stability: The design holds the door true with bolts at both the top and bottom, reducing reliance on the handle for stability.
Installation Notes:
- Latch Reversal: To reverse the latch, insert a flat-bladed screwdriver into the rectangular slot above the spindle while pulling out the latch. Reverse the latch and reinsert it for proper functionality.
Product Specifications:
- Manufacturer: GU
- Backset: Selectable (refer to measurement guide)
- Centres PZ: 92mm (measurement guide available)
- Faceplate: Selectable (measurement guide available)
- Spindle Size: 8mm
- Deadbolts: 4
- Latch: 1
- Main Gearbox: Latch & deadbolt
- Operation: Selectable (refer to operation guide)
- Spindle: Split 8mm
- Handing: Non-handed
- Distance Between Inner Locking: 1590mm
- Height: 1770mm
- Top Deadbolt to Spindle: 308mm
- Bottom Deadbolt to Spindle: 1282mm
Recommendation: For optimal use, we suggest pairing the GU Secury A2 lock with a pull handle and separate escutcheon instead of lever handles. This combination enhances both functionality and aesthetics.
Ensure your door security with the GU Secury A2 lock, combining modern technology with traditional design for a reliable locking solution.
