Product Information
ERA locks may also be stamped with brands such as Homesafe, Surelock, Saracen, Spartan, Duraflex, Supa, Westward, or Cego.
Originally designed to replace GU, Lockmaster, and Winkhaus locks without the need for new routing positions, these locks are available in two options.
All ERA locks are compatible with the gearboxes listed below. Please inquire with us for more details.
- Backset Options: 28mm, 30mm, 35mm, and 45mm.
- Centres: 92mm
- Operation: Lift lever or split spindle nightlatch.
- Latch Reversal: To reverse the latch, undo the screws (depending on the model), remove the latch, reverse it, reinsert, and replace the screws.
Product Specification
- Manufacturer: ERA
- Backset: Select from drop-down - How do I measure the backset?
- Centres PZ: 92mm - How do I measure the centres?
- Faceplate: Select from drop-down - How do I measure the faceplate?
- Spindle Size: 8mm
- Rollers: 4
- Deadbolts: 1
- Latch: 1
- Main Gearbox: Latch & deadbolt
- Operation: Select from drop-down - What is the operation?
- Spindle: Split 8mm
- Handing: Non-handed
- Distance Between Inner Locking: 670mm
- Distance Between Outer Locking: 1610mm
- Height: 2250mm
- Top Roller to Spindle: 730mm
- Bottom Roller to Spindle: 880mm
- Door Material: UPVC, Aluminium
