Description
Product Overview
Introducing our high-quality gearbox designed for seamless integration with thermic and euro groove profiles. This gearbox minimizes the need for machining on door profiles, ensuring a hassle-free installation process. The innovative closed lockcase design effectively prevents machining chips from entering the internal mechanism, enhancing durability and reliability.
Key Features
- Backset: 30mm
- Centres PZ: 85mm
- Faceplate Length: 300mm
- Faceplate Width: 25mm
- Height: 175mm
- Spindle Size: 8mm
- Main Gearbox: Latch and deadbolt
- Handing: Non-handed
- Cylinder Type: Euro profile
- Lockcase Thickness: 15mm (slim lockcase)
- Material: Stainless steel internal components and faceplate, zinc/plastic plated steel lockcase and cover
- Deadbolt Thickness: 8mm, excursion 24mm
- Adjustable Latch Bolt: Approximately 5mm, interchangeable with roller bolt or plug
- Compatibility: Can be paired with additional locking points kits for up to 5 locking points
- Packaging: Loose
Product Specification
- Manufacturer: Omec
- Backset: 30mm
- Centres PZ: 85mm
- Height: 175mm
- Main Gearbox: Latch and deadbolt
- Spindle: 8mm
- Faceplate Length: 300mm
- Handing: Non-handed
- Cylinder Type: Euro
- Genuine/Copy: Genuine
- Packaging: Loose
- Faceplate Width: 25mm
Measuring Guidelines
- How to Measure the Backset: Measure from the edge of the door to the center of the keyhole.
- How to Measure the Centres: Measure the distance between the center of the keyhole and the center of the handle hole.
This gearbox is engineered for optimal performance and longevity, making it an ideal choice for your locking needs.
