Description
Product Information
Introducing the Alpro ANSI style release, expertly designed for both metal and timber doors. This versatile release is commonly paired with latches, including narrow style dead latch mortice locks, particularly effective on aluminium doors.
Key features include a robust 124mm long stainless steel faceplate and selectable operation at either 12v or 24v, depending on your wiring needs. The release is also field reversible, allowing you to switch between fail-safe and fail-secure modes with ease. For those requiring AC power, an additional RM1 rectifier module is available for separate purchase. For more detailed assistance, feel free to reach out to our technical team.
Product Specification
- Type: Mortice
- Style: ANSI
- Jaw: Non adjustable
- Dimensions: (H) 124mm x (W) 31mm x (D) 35mm
- Field Reversible: Fail safe / fail secure
- Current Consumption: 200mA at 12v DC, 100mA at 24v DC
- Holding Force: 1750kg
- Latch Accommodation: 13mm (including 3mm air gap)
