6345 2 Hooks Timber and Composite Repair Multipoint Door Lock

Product Overview: ERA Lock for Timber and Composite Doors

The ERA lock is expertly crafted for remedial work on timber and composite doors, ensuring enhanced security and functionality.

Key Features:

• Design: Features 2 high-security hooks for superior anti-separation resistance.
• Faceplate & Backset: Equipped with a 20mm faceplate and a 45mm backset for compatibility with various door types.
• Keep Set: Comes with a non-handed keep set, allowing for versatile installation.
• Lock Set: Includes a 3-piece lock and keep set, along with a pack of fixing screws and a set of packers for easy installation.

Operation:

• Lever Mechanism: Operates via a lift lever or split spindle nightlatch mechanism for user-friendly access.

Latch Reversal Instructions:

1. Undo the screw in the latch to remove it.
2. Reverse the latch, reinsert it, and replace the screw.

Nightlatch Reversal Instructions:

1. Remove the latch to expose a small screw.
2. Use a small bladed screwdriver to turn the screw 180 degrees.
3. Return the latch to its correct position.

This ERA lock is an ideal choice for those seeking a reliable and secure locking solution for their doors.

Product Specification

1. • Centres: 92mm
2. • Case Height: 221mm
3. • Case Depth: Backset + 18mm
4. • Overall Length: 1960mm
5. • Minimum Length: 1040mm
6. • Maximum Top Hook to Spindle: 816mm
7. • Minimum Top Hook to Spindle: 360mm
8. • Maximum Bottom Hook to Spindle: 871mm
9. • Minimum Bottom Hook to Spindle: 415mm
